M3TEK

High Efficiency 2A 1.5MHz Single Cell Li-ion Battery Switching Charger

Description

The MT2011 is a 4.5-20V input, 2A single-cell synchronous Li-Ion battery switching charger, suitable for portable application. The MT2011 integrates a synchronous PWM controller, 20V rating power MOSFETs, current sense resistor, high-accuracy current and voltage regulation, and charge termination, into a compact 8-pin SOP_EP package.

 Features

      · 1.5MHz Synchronous Switching Charger with Integrated Power FETs

· Up to 93% Efficiency

· 20V Input Rating with 6.7V OVP

· Programmable (2A Max) Charge Current

· Built-in Charge Current Soft Start

· Built-in Reverse Current Blocking Diode

· Built-in Charge Current Sense Resistor

· Output Short Circuit Protection

· Over Temperature Protection

· Pb-Free(ROHS compliant)

· Available in a SOP8_EP Package

Applications

 · Tablet PC, Ebook and Netbook

 · Handheld Portable Media Products

 · Power Bank
